Standard Vehicle GPS Tracker (Non-Voice)

Model: JM-VG03

The Standard Vehicle GPS Tracker (Non-Voice) is a compact, high-performance tracking solution designed for cars, motorcycles, and fleet vehicles. With real-time tracking, advanced safety alerts, and durable IP65 protection, this device ensures complete vehicle security and control at an affordable cost.

Key Features

• Real-time vehicle tracking with high-precision GNSS
• Driving behavior analysis (basic)
• Remote engine/fuel cut-off support (relay required)
• Geo-fence zone creation with instant alerts
• Ignition (ACC) status detection
• Overspeed, low battery, power disconnection & movement alerts
• IP65 dust & water resistant rugged design
• Suitable for personal vehicles and fleet management

Positioning & Performance

• Positioning System: GPS + BDS + LBS
• Positioning Accuracy: < 2.5m CEP
• Tracking Sensitivity: -162 dBm
• Acquisition Sensitivity: -148 dBm
• TTFF (Open Sky):
o Hot Start: ≤ 1 second
o Cold Start: ≤ 35 seconds

Network & Connectivity

• Communication Network: GSM
• Frequency Band: Quad-band 850 / 900 / 1800 / 1900 MHz

Power & Interface

• Backup Battery: 60mAh / 3.7V industrial-grade Li-Polymer
• Input Voltage: 9–90V DC
• SIM Type: Micro-SIM
• LED Indicators: GPS (Blue), GSM (Green)
• Data Storage: 32MB + 32MB
• Interface: 4-Pin (V+, V-, ACC, Relay)

Physical & Environmental Specifications

• Dimensions: 79 × 38 × 14 mm
• Weight: 29 g
• Operating Temperature: -20°C to 70°C
• Protection Rating: IP65

Safety Alerts & Driving Analysis
Driving Behavior Analysis (Basic)

• Harsh acceleration
• Harsh braking
• Harsh cornering
• Collision detection

Smart Alerts

• Vehicle movement alert
• Overspeed alert
• Geo-fence entry/exit alert
• Vehicle battery detection
• External power disconnection alert
